Lunchbox Zissou 54 - LBZ54
Lunchbox Zissou 54 - LBZ54
$295.00+
Only 1 available
Almost gone. There's only 1 left.
-
Handmade
Portable 54hp case for Eurorack and Tiles
The Lunchbox Zissou cases are the latest in the lunchbox series of portable Eurorack + 1U Tile cases. Zissou cases feature removable lids, a versatile power supply that is capable of running from 9V to 18Vdc and a tough exterior. The LBZ54 is an compact 54hp case in a 1U+3U+1U configuration.
54hp Eurorack
108hp 1U Tiles (2 Rows)
Clearance from top rails to bus board: 6cm (2.35”)
Clearance above rails: 5.5cm (2.15”)
Case can be closed while patched
Shock-Mount Rack Frame
Includes 100 M2.5 x 6mm screws
Removable lid with sliding pull pins
Optional stand for vertical configuration
Optional Reverb Tank – Accutronics AMC2BF2
Optional “Outputs” Tile with 1/4″ jacks on side of case
Power:
DC-DC converter followed by filtering and linear regulation
Power from a +9V to +18VDC power adapter or battery pack
+12V rail 1000mA
-12V rail 1000mA
+5V rail 500mA
10 Shrouded 16-pin Eurorack connections
15 Keyed 1U Tile connections
Includes 12V – 4.2A DC Power Adapter and US style IEC cord
Uses a 2.1mm x 5.5mm center positive power connector
Size:
34.25cm (13.5”) Wide
29.25cm (11.5″) Deep
15.25cm (6″) Tall
2.5kg (5.5lbs)Unloaded Weight
Mounting Hardware:
Choice of M2.5 Threaded Strips or M2.5 Sliding Nuts
Options:
-O + $60
Outputs Tile with headphone and stereo output jacks on side of case
-S + $20
Accutronics AMC2BF2 Spring Reverb tank mounted with vibration dampers
1U Tile Info: http://pulplogic.com/1u_tiles
1–2 weeks
There was a problem calculating your shipping. Please try again.
691 reviews
5 out of 5 starsBuyers are raving!
Multiple people gave 5-star reviews to this shop in the past 7 days.
William Jan 15, 2019
Heavy duty, high quality, build and assembly are great, power supply is quiet, and the 54hp of 3u combined with 108hp of 2x1u tile rails makes this an exceptional portable case, and a bargain in this market. John Kennedy answered all my questions professionally and in a timely manner, and the turn around time from placing an order to delivery was very fast!!! I look forward to ordering more utility tiles from Pulp Logic very soon.
Daniel Sine Jun 2, 2018
An affordable and solid little case which has quickly grown to be one of my favorite things. I'm not sure if it's apparent in the photos and description, but it DOES have an on/off switch on the side.
dbrenner5 Nov 8, 2019
Incredible service, fast shipping, and quality build. Thanks John!
James Cooley Sep 22, 2018
Built to order and tough as a tank great little portable case. Cables fit when lid closes while patched, but not with stackables so I recommend a multiple or two.
Photos from reviews
